Matrix S Soft Close Assembled Drawer System FSC Certified - 135mm

The Matrix box slim s drawer set is a 35kg capacity drawer system that comes with full extension, under mounted runners and soft and smooth closing mechanism on both sides. The drawer sides are 84mm. The drawer is designed to fit a 16mm drawer base and rear panel.

• Soft-close
• Height: 84mm
• Powder-coated steel
• Colour: grey/anthracite
• Back panel height: 135mm
• Sides: powder-coated steel
• Drawer sides depth: 450mm
• Load bearing capacity: 35kg
• Bases and back: 16mm thick (MFC board)
• Minimum internal depth required: 460mm
• Drawer back and base from an FSC® certified

Please be aware that:

• Drawer front not included

Specifications:

• 300mm cabinet requires 264mm internal width
• 400mm cabinet requires 364mm internal width
• 450mm cabinet requires 514mm internal width
• 500mm cabinet requires 464mm internal width
• 600mm cabinet requires 564mm internal width
• 800mm cabinet requires 764mm internal width
• 900mm cabinet requires 864mm internal width
• 1000mm cabinet requires 964mm internal width
